BCM TRANSTECH TOOL STORAGE SOLUTIONS -





We are proud to represent BCM Transtech, based in Denmark since 1976, focusing on the development of innovative and optimal storage and handling solutions for corrugated tooling, including rotary and flat cutting dies, as well as printing plates.

Some of the benefits of BCM tool storage and management solutions include:

• Highly space- and time efficient.
• Improved control of tool inventory.
• Reduced need for storage space up to ceiling height.
• Reduced need for heavy lifting by operators.
• Reduced risk of damage to tooling.

Modular designs are available based on overall tooling size, capacity requirements, and storage space availability within your plant.

Rotary Die Storage Solutions

Fully Automatic

The BCM AutoStorage is an automatic solution designed to efficiently handle and store rotary cutting dies of all sizes and formats.

• Less manual handling, reducing the risk of injuries and human error.
• Tracks and safeguards tooling until required.
• Reduced reliance on storage personnel.
• Easy-to-operate systems.
• Maximized space and time efficiency.
• Computer-controlled storage from the operator desk, with optional upgrades.
• Secure storage data with a reliable database.

Semi-Automatic

BCM SmartStorage systems include advanced features to assist tooling departments. While the crane is manually moved, storage positioning, lifting, and lowering are semi-automated for improved efficiency.

• Prolongs the lifespan of rotary dies.
• Reduces maintenance costs.
• Enhances safety standards.
• Programmable system using existing tooling numbers.
• Handheld wireless scanners for tooling recognition.
• Positioning assistance for accurate placement.
• Programmed height settings for fast and safe handling.
• Easy-to-operate systems.

Manual

The BCM PrimeStorage is a high-quality, user-friendly storage system for rotary dies. The system includes a rack and roof-supported crane rail with a manual gantry crane.

• Lightweight gantry crane.
• Improved safety standards with no heavy lifting.
• Electro-mechanical safety system.
• Camera-assisted operation.
• Easy to use and easy to train.
• Handles rotary dies of various sizes and formats.
• Frequency-regulated hoist for precise handling.
• Highly versatile.

Flat Die Storage Solutions

Fully Automatic

The Intelligent and Automated Storage Solution. The BCM AutoStorage is fully automatic. Once the operator places the transport trolley in the garage, the rest is managed via the operator’s computer. The storage robot retrieves used dies and replaces them with new ones, ready for production

• Operate a large tooling warehouse with minimal staffing.
• Improve safety standards by eliminating heavy lifting.
• Minimize human error with easy to locate dies.
• Free up operator time for more value-added tasks.
• Minimize the risk of dies getting lost or damaged with automated handling.
• Securely store information in a robust database.
• Reduce the need for storage operators.
• Enhance health and safety standards.

Semi-Automatic

Enhance Your Storage with Smart Features for the Future. BCM SmartStorage systems provide semi-automatic handling solutions for your cutting die warehouse.

• Store die information in the database for quick location.
• User-friendly, whilst reducing the risk of human error.
• Customizable, modular storage system.
• The operator manually moves the crane while lifting and lowering are semi-automated.
• Intelligent die position locator—use your order number to search for dies in the database, and the operator is guided to the correct location on screen.

Manual

Increase Your Storage Capacity! The BCM PrimeStorage - loved by customers worldwide

• Simple and intuitive with camera-assisted guidance.
• Very space efficient storage solution.
• Electro-mechanical safety system.
• Features a highly customizable rack system for BCM Foldable Cassettes, designed for flatbed die sets up to 2.1 meters in length.
• A manually operated crane facilitates safe and efficient handling of tooling cassettes to and from the storage rack and transport trolley.
• The crane is manually operated, with lifting and lowering controlled via frequency-regulated push buttons for the hoist unit.
• The electro-mechanical safety system safeguards the operator from human error during crane operation.

Plate Storage Solutions

Fully Automatic

The BCM AutoStorage maximizes factory efficiency by leveraging vertical space, streamlining processes, and integrating intelligent storage solutions. The BCM AutoStorage maximizes factory efficiency by leveraging vertical space, streamlining processes, and integrating intelligent storage solutions.

• Protect your tooling and extend the lifespan of printing plates.
• Simplify and enhance your printing plate storage and logistics.
• Introduce automation and intelligence to your factory operations.
• Operate high-capacity storage with fewer staff and reduced risk of human error through intelligent automation.
• Utilize BCM’s expertise in automation to optimize your operations.
• Manage complete production sets in a single retractable profile, ready for direct transfer to printers.

Semi-Automatic

Utilize the Factory Height and Increase Capacity. BCM SmartStorage is highly customizable to accommodate various types and sizes of printing plates.

• Maximize storage capacity.
• Minimize manual handling.
• Intelligently manage storage.
• Store location data in a database, reducing reliance on operator memory.
• Store an entire production set in one retractable profile.
• Optimize factory storage by utilizing vertical space efficiently.
• Minimize the risk of losing printing plates, which can cause production delays and disruptions, by storing them intelligently with BCM.
• Minimize manual handling—send the profile with the full production set directly to printers.
• Choose from a wide range of profile types, with optional customer-specific profiles available - up to 8 colors per profile.

Manual

Space Efficient Printing Plate Storage. BCM manual Printing Plate Storages are the ideal solution for facilities requiring high storage capacity. Racks can be installed near the printing machine for high-frequency orders or in centralized storage areas for less frequent use

• Fully customizable modular designs.
• A wide range of profile types available.
• Securely stores printing plates by hanging them.
• Multi-level storage systems with staircase access to upper levels.
• Durable and robust rack system.
• Extensive range of storage profiles to meet diverse requirements to meet every need.
• Optimize the balance between storage capacity and operator comfort by selecting the appropriate profile for your printing plates.
• Available with 8, 12, 15, 18, or 21 hooks per profile.
• The type of stereo profile required depends on the space needed for each printing plate. Factors such as printing plate design, backing material, and other specifics determine the ideal setup. BCM offers tailored solutions to match your needs.

BCM Work and Time Saving Solutions

BCM Mobilator for Rotary & Flat Dies

The BCM Mobilator for Rotary Dies offers multiple variations tailored to machine type and die cutter design. Each Mobilator makes cutting dies virtually weightless, eliminating the need for heavy lifting by operators.

• Eliminate the need for heavy lifting.
• Wide range of solutions to suit all machine types.
• Telescopic and/or curved rails customized for closed machines, positioning cutting dies directly in front of the cutting unit.
• BCM Mobilators eliminate manual handling between BCM tooling trolley and converting machine.
• Existing cutting dies can be easily modified for Mobilator handling, using BCM-supplied modification tools to install threaded inserts.
• Operators can singlehandedly replace large-format cutting dies without assistance.

BCM Tool (Job) Trolleys

Preload the dies, plates and inks for the next job to minimize machine setup times. For Handling Multiple Jobs, Ink, and Tooling Types. The BCM Multi Purpose Transport Trolleys are indeed “Multi Purpose”, due to their ability to hold production materials for multiple jobs to ensure continuous machine operation.

• High-capacity trolleys support multiple jobs, keeping machines running longer.
• Can be used with or without factory logistics systems (e.g., conveyor systems and transfer cars).
• Each trolley is tailored to the specific machine it serves.
• Endless configurations available—contact us to learn more.

Contact us today for a customized BCM solution recommendation for your plant.
